Milwaukee Shed Design Specifications

Custom Shed Walls

• All walls are 2x4s 16" OC stud spacing unless something else is specified
• Pressure treated bottom plates when building on concrete slabs
  *regular lumber all other times
• Double top plates on all of our walls
• We use 5/8" LP smart panel for our siding
• Gable buildings come standard with 6" soffits on the eaves, freeze board on the gables
• Barn roof buildings have a 5-1/2" soffits on all sides
• Quakers have 5-1/2" soffits on all sides as well

Storage Shed Floors

• All sheds have 2x4 floors with 12" OC (on center) spacing
• 8' wide buildings have two pressure treated 4x4 runners
• 10' wide buildings (delivered) have four pressure-treated runners
• 12' wide buildings (delivered) have four pressure-treated runners
• 10' buildings built on site have three pressure-treated runners
• We use 5/8" LP Prosrtuct for our shed floors
• Our floor joists are pole barn nailed to the 4x4 runners
  *not toe-nailed like most other shed builders

Storage Shed Roof Structure

• 2x4s 24" OC for roof rafters
• We use 1/2" OSB for our roof sheathing, not 7/16"
• All buildings get H-clips between the plywood seams where applicable
• 5/8" plywood gusset plates at the peak of all rafters
• Hurricane clips at no charge when required by local municipality
• 2x4 collar ties on every other rafter

Shed Roof Shingles

• 35-year dimensional shingles standard on all of our buildings
• 15 lb felt is standard on all of our buildings
• Galvanized metal d-edge standard on all roof edges
• 2 gable vents included on all buildings
• 9 colors to choose from
  *or we can match your house's color

Milwaukee Storage Shed Hardware

• Powder-coated black hardware is standard
• Doors come with a keyed t-handle type lock
• Spring-loaded barrel bolts keep non-active doors closed when not in use
• Windows can be added to the shed or the doors to achieve your desired look

Custom Shed Siding & Trim

We use 5/8" LP Smart Panels that come pre-primed from the factory for siding.

3/4" LP Smart Trim boards for corner boards and fascia. Also pre-primed from the factory.

Atlas Roofing Shingle Colors
